Titan Micropiles

Main advantages:

  • Adaptable to any load situation
  • Short installation time
  • Small equipment for installation
  • For tension and compression or combined loads

Technical specifications:
Anchor/pile typeTitan
30/16		Titan
30/14		Titan
30/11		Titan
40/20		Titan
40/16		Titan
52/26		Titan
73/53		Titan
73/56		Titan
103/78		Titan
105/53
Nominal outside dia.mm3030304040527373103105
Nominal inside dia.mm16141120162653567853
Ultimate loadkN2202603205396609291160119419503460
YieldkN18022026043052573097078515702750
Yield stress T 0.2N/mm2470610580590590550590550500500
Cross section (A)mm238239544672687913371631141431465501
Weightkg/m3.03.13.55.66.910.512.811.124.743.5
Thread left/right hand-leftleftleftleftleftrightrightrightrightright
Lengthsm43/42/3/433336.2533

We reserve the right to change technical specifications without prior notice.
