H-Bearing Piles

H-Bearing Piles

Section	Mass	Depth	Height	Area	Moment of Inertia		Section Modulus
	kg/m	mm	mm	cm2	ly cm4	lz cm4	Wy cm3	Wz cm3
HP 220 x 57.2	57.2	210	224.5	72.85	5729	2079	545.6	185.2

HP 260 x 75	75	249	265	95.54	10650	3733	885.1	281.7
HP 260 x 87.5	87.3	253	267	111.2	12590	4455	994.9	333.7

HP 305 x 88	88	301.7	307.2	111.6	18380	5949	1218	387.3
HP 305 x 95	95	303.8	303.8	121.7	20170	6552	1328	425.1
HP 305 x 110	110	307.9	310.3	140.2	23550	7680	1530	495.0
HP 305 x 126	126	312.4	312.5	161.6	27540	9019	1763	577.2
HP 305 x 149	149	318.5	315.6	190.0	33050	10870	2075	688.8
HP 305 x 186	186	328.3	320.5	237.0	42580	14090	2594	879.3
HP 305 x 223	223	338.0	325.4	285.0	52480	17590	3127	1081

HP 320 x 88.5	88.5	303	304	112.7	18740	5634	1237	370.6
HP 320 x 103	103	307	306	131.0	22050	6704	1437	438.2
HP 320 x 117	117	311	308	149.5	25480	7815	1638	507.5
HP 320 x 147	147	319	312	186.9	32670	10160	2048	651.3
HP 320 x 184	184	329	317	234.5	42340	13330	2574	841.2

HP 360 x 109	109	346.4	370.5	138.9	30620	10940	1768	590.7
HP 360 x 133	133	351.9	375.3	168.5	37730	13540	2144	725.3
HP 360 x 152	152	356.4	375.5	193.8	43950	15810	2466	842.3
HP 360 x 174	174	361.5	378.1	221.7	51020	18400	2823	973.5

HP 400 x 122	122	348	390	155.9	34770	13850	1998	710.3
HP 400 x 140	140	352	392	178.6	40270	16080	2288	820.2
HP 400 x 158	158	356	394	201.4	45940	18370	2581	932.4
HP 400 x 176	176	360	396	224.3	51770	20720	2876	1047
HP 400 x 194	194	364	398	247.5	57760	23150	3174	1163
HP 400 x 213	213	368	400	270.7	63920	25640	3474	1282
HP 400 x 231	231	372	402	294.2	70260	28200	3777	1403

The sections can be delivered in all standard grades after agreement.
Please contact us for tolerances and other steel sections.

We reserve the right to change technical specifications without prior notice.
